Key specifications
- Part numbers
- 24 options — see the table below
- Size
- 65mm
- Parts
- Adaptor: Forged Aluminium on all; Barrel: 600mm Aluminium, Barrel: 750mm Aluminium, Barrel: 900mm Aluminium depending on part number
- Connection type
- BSP, Storz, CFA, MFB, NSW, QRT, SA, BI
- Male / female
- Male outlet (some part numbers)
Part numbers & specifications
| Part No. | Description | Partsother than Adaptor: Forged Aluminium | Connection type | Male / female |
|---|---|---|---|---|
| 138001 | Standpipe 65mm BSP Male Single Outlet with H/Wheel & 600mm Aluminium Barrel | Barrel: 600mm Aluminium | BSP | Male outlet |
| 138002 | Standpipe 65mm Storz Single Outlet with H/Wheel & 600mm Aluminium Barrel | Barrel: 600mm Aluminium | Storz | - |
| 138003 | Standpipe 65mm CFA Male Single Outlet with H/Wheel & 600mm Aluminium Barrel | Barrel: 600mm Aluminium | CFA | Male outlet |
| 138004 | Standpipe 65mm MFB Male Single Outlet with H/Wheel & 600mm Aluminium Barrel | Barrel: 600mm Aluminium | MFB | Male outlet |
| 138005 | Standpipe 65mm NSW Male Single Outlet with H/Wheel & 600mm Aluminium Barrel | Barrel: 600mm Aluminium | NSW | Male outlet |
| 138006 | Standpipe 65mm QRT Male Single Outlet with H/Wheel & 600mm Aluminium Barrel | Barrel: 600mm Aluminium | QRT | Male outlet |
| 138007 | Standpipe 65mm SA Male Single Outlet with H/Wheel & 600mm Aluminium Barrel | Barrel: 600mm Aluminium | SA | Male outlet |
| 138008 | Standpipe 65mm BI Male Single Outlet with H/Wheel & 600mm Aluminium Barrel | Barrel: 600mm Aluminium | BI | Male outlet |
| 138017 | Standpipe 65mm BSP Male Single Outlet with H/Wheel & 750mm Aluminium Barrel | Barrel: 750mm Aluminium | BSP | Male outlet |
| 138018 | Standpipe 65mm Storz Single Outlet with H/Wheel & 750mm Aluminium Barrel | Barrel: 750mm Aluminium | Storz | - |
| 138019 | Standpipe 65mm CFA Male Single Outlet with H/Wheel & 750mm Aluminium Barrel | Barrel: 750mm Aluminium | CFA | Male outlet |
| 138020 | Standpipe 65mm MFB Male Single Outlet with H/Wheel & 750mm Aluminium Barrel | Barrel: 750mm Aluminium | MFB | Male outlet |
| 138021 | Standpipe 65mm NSW Male Single Outlet with H/Wheel & 750mm Aluminium Barrel | Barrel: 750mm Aluminium | NSW | Male outlet |
| 138022 | Standpipe 65mm QRT Male Single Outlet with H/Wheel & 750mm Aluminium Barrel | Barrel: 750mm Aluminium | QRT | Male outlet |
| 138023 | Standpipe 65mm SA Male Single Outlet with H/Wheel & 750mm Aluminium Barrel | Barrel: 750mm Aluminium | SA | Male outlet |
| 138024 | Standpipe 65mm BI Male Single Outlet with H/Wheel & 750mm Aluminium Barrel | Barrel: 750mm Aluminium | BI | Male outlet |
| 138033 | Standpipe 65mm BSP Male Single Outlet with H/Wheel & 900mm Aluminium Barrel | Barrel: 900mm Aluminium | BSP | Male outlet |
| 138034 | Standpipe 65mm Storz Single Outlet with H/Wheel & 900mm Aluminium Barrel | Barrel: 900mm Aluminium | Storz | - |
| 138035 | Standpipe 65mm CFA Male Single Outlet with H/Wheel & 900mm Aluminium Barrel | Barrel: 900mm Aluminium | CFA | Male outlet |
| 138036 | Standpipe 65mm MFB Male Single Outlet with H/Wheel & 900mm Aluminium Barrel | Barrel: 900mm Aluminium | MFB | Male outlet |
| 138037 | Standpipe 65mm NSW Male Single Outlet with H/Wheel & 900mm Aluminium Barrel | Barrel: 900mm Aluminium | NSW | Male outlet |
| 138038 | Standpipe 65mm QRT Male Single Outlet with H/Wheel & 900mm Aluminium Barrel | Barrel: 900mm Aluminium | QRT | Male outlet |
| 138039 | Standpipe 65mm SA Male Single Outlet with H/Wheel & 900mm Aluminium Barrel | Barrel: 900mm Aluminium | SA | Male outlet |
| 138040 | Standpipe 65mm BI Male Single Outlet with H/Wheel & 900mm Aluminium Barrel | Barrel: 900mm Aluminium | BI | Male outlet |
