Key specifications
- Part numbers
- 10 options — see the table below
- Sizes
- 20mm, 15mm, 25mm, 32mm, 40mm, 50mm, 65mm, 80mm, 100mm
- Material
- Forged Brass
- Connection type
- BSP, Hose barb
- Male / female
- Female
Part numbers & specifications
| Part No. | Description | Size |
|---|---|---|
| 211001 | Brass 20mm BSP Female Nut X 15mm Barbed Tail | 20mm, 15mm |
| 211002 | Brass 20mm BSP Female Nut X 20mm Barbed Tail | 20mm |
| 211003 | Brass 25mm BSP Female Nut X 20mm Barbed Tail | 25mm, 20mm |
| 211004 | Brass 25mm BSP Female Nut X 25mm Barbed Tail | 25mm |
| 211005 | Brass 32mm BSP Female Nut X 32mm Barbed Tail | 32mm |
| 211006 | Brass 40mm BSP Female Nut X 40mm Barbed Tail | 40mm |
| 211007 | Brass 50mm BSP Female Nut X 50mm Barbed Tail | 50mm |
| 211008 | Brass 65mm BSP Female Nut X 65mm Barbed Tail | 65mm |
| 211009 | Brass 80mm BSP Female Nut X 80mm Barbed Tail | 80mm |
| 211010 | Brass 100mm BSP Female Nut X 100mm Barbed Tail | 100mm |
