100mm R/G Dual Rear (Back) Entry Booster - Stainless Steel 304 Grade supplied with 65mm pressure gauge caps or plugs.
Key specifications
- Part numbers
- 7 options — see the table below
- Size
- 100mm
- Material
- Stainless Steel
- Parts
- Inlet: Aluminium (some part numbers)
- Connection type
- Storz, CFA, MFB, QRT, NSW, SA, BI
Part numbers & specifications
| Part No. | Description | Parts | Connection type |
|---|---|---|---|
| 133066 | Ss 100mm Class 35 Rear Entry Booster With Aluminium Storz Inlets | Inlet: Aluminium | Storz |
| 133067 | Ss 100mm Class 35 Rear Entry Booster With Cfa Inlets | - | CFA |
| 133068 | Ss 100mm Class 35 Rear Entry Booster With Mfb Inlets | - | MFB |
| 133069 | Ss 100mm Class 35 Rear Entry Booster With Qrt Inlets | - | QRT |
| 133070 | Ss 100mm Class 35 Rear Entry Booster With Nsw Inlets | - | NSW |
| 133071 | Ss 100mm Class 35 Rear Entry Booster With Sa Inlets | - | SA |
| 133072 | Ss 100mm Class 35 Rear Entry Booster With Bi Inlets | - | BI |
